Modularized assembly technology facilitates transport and maintenance. Vibrating screen is made of high-strength steel plate, connected by ring-shaped rivet, which ensures steady and reliably working. The equipment is driven by two-sided high-power motors with a large amplitude and high screening efficiency. The smart control systems of ZMS2065G mobile screen has the function of One-button process start & stop, remote real-time diagnostics & easy process optimization. The ZMS2065G mobile screen is equipped with load-sensitive hydraulic control system, which has the advantages of low caloric value, less power loss, accurate and safe control.
| Main Parameters | Unit | Value |
| Capacity | t/h | 150-350 |
| Screen Size | mm | 2000×6500 |
| Screen Area | m² | 13 |
| Number of Screen Mesh Layers | \ | 3 |
| Transport size Width x Length x Height | m | 14.3×3.72×4.12 |
| Engine Power | kW | 103 |
| Driving Power | kW | 62.5 |
| Total Weight | t | 35 |
| Power Type | \ | city-electric drive |
| Note: External mains (three-phase power 380-450V, 50Hz) or external generator set (complete with mobile crushing station) | ||
